MYFOG® - Mist generator for airflow visualisation testing

The ISO 14644-3 Annex B7 International Standard states that the airflows in all classified environments of any ISO class, should be visually verified every 24 months.

Among the suggested methods is the generation of tracers that will clearly visualise speed and direction of the airflows. The test is carried out in the areas of interest by taking pictures of the airflows made visible by the fog during “at rest” conditions (with no personnel present and no production equipment in use). The purpose of this test is to verify and certify that the airflow designed and installed to protect the critical areas is working efficiently.

The MYFOG® stops the need for using oil based smoke that soil the cleanroom and instead relies only on mist generation from sterile water which in turn makes clean up after testing a lot easier.

Benefits:

  • Simple to use
  • No gas supply, no consumables, no oil
  • Remote control with start/stop, mist speed and intensity adjustment



The System:

  • 2.8” TFT touch screen
  • Water level display with status colour guide
  • Temperature monitoring and diagnostics with graphic visualisation
  • Fog density adjustment
  • Fan rotation speed adjustment (fog diffusion speed)
  • Monitoring of operation times
  • Pause function with storing of current generation settings
  • Menu available in Operator mode (viewing only) and Supervisor mode (changes allowed)
  • Wide range of accessories available

Applications for the MYFOG®



Classified environment laminar flow areas (e.g.: liquid filling machines)
Weighing stations (e.g.: powder weighing and sampling areas)
Llaminar flow cabinets
​Balancing pressures between rooms (visual indication)
Identification of air stagnation pockets
​​Personnel training

Accessories Included:

Remote control

Flexible tubing: diameter 80mm and length 3.3m

Carrying case with castors

Supplied by:

AB Scientific are proud to be the exclusive distributors for AM Instruments in the UK & Ireland.

Established in 1990, AM Instruments have a mission to become the benchmark in contamination control products. Oriented towards GMP with ISO 9001:2015 certification, they provide high quality cleaning products and systems, for your laboratory, manufacturing facility, and other controlled areas.

AM Instruments are leading manufacturers of standard and customised contamination control units and systems, stainless steel furniture, cleaning products and accessories.
